Product Details:
|
| Standard: | AiSi | Type: | Equal |
|---|---|---|---|
| Model Number: | 310S, 410, 316Ti, 316L, 316, 321, 410S | Processing Service: | Bending, Welding, Decoiling, Punching, Cutting |
| Surface Finish: | 2B | Shape: | Equal Angle Bar |
| Grade: | 200 Series 300 Series 400 Series | Application: | Construction, Building Construction Material |
| Tolerance: | ±1% | Steel Grade: | 301L, S30815, 301, 304N, 310S, S32305, 410, 204C3, 316Ti, 316L, 441 |
| Product Name: | 304 Stainless Angle Steel Bar | Technique: | Hot Rolled Cold Rolled |
| Material: | 200 Series/300 Series/400series | Payment Terms: | 30%T/T Advance + 70% Balance |
| Length: | 6-12m Or Customer's Requiremnts | ||
| Highlight: | 2B 310S Stainless Steel Angle,316Ti Stainless Steel Angle,316 stainless angle iron 50x5 |
||
Factory Price AISI 201 304 316 Stainless Steel Angle Bar 40x3 45x4 50x5 SS Angle Bar With Stock
Stainless Steel Angle is used to make frames, brackets and for general engineering and manufacturing fabrications. It is a good material choice as it does not rust or stain due to the interaction of alloying elements, such as molybdenum, nickel, and chromium, with the environment; without these alloying elements, the iron in the steel would be prone to cause oxidisation, rust, and staining.
It is available in two grades, 304 and 316.The 304 grade is the general commercial grade, easy to machine and form, very good for welding and good corrosion resistance.
The 316 grade has better corrosion resistance and is recommended for marine or coastal applications.
|
Specification
|
Angle bar
|
Size: 3mm*20mm*20mm~12mm*100mm*100mm
|
|
Quality test
|
we can offer MTC (mill test certificate)
|
|
|
MOQ
|
500 kilograms
|
|
|
Payment terms
|
L/C T/T (30%DEPOSIT)
|
|
|
Stock or not
|
enough stock
|
|
|
Packing
|
Bundled,wooden box for export standard package
|
|
|
Delivery time
|
7-15 dyas,or according to the order quantity or upon negotiation
|
|
|
item
|
value
|
|
Standard
|
AiSi
|
|
Grade
|
200 series 300 Series 400 series
|
|
Type
|
Equal
|
|
Application
|
Construction
|
|
Place of Origin
|
China
|
|
|
Jiangsu
|
|
Brand Name
|
Tisco
|
|
Model Number
|
310S, 410, 316Ti, 316L, 316, 321, 410S, 410L, 430, 309S, 304
|
|
Tolerance
|
±1%
|
|
Processing Service
|
Bending, Welding, Decoiling, Punching, Cutting
|
|
Steel Grade
|
301L, S30815, 301, 304N, 310S, S32305, 410, 204C3, 316Ti, 316L, 441, 316, L4, 420J1, 321, 410S, 410L, 436L, 443, LH, L1, S32304, 314, 347, 430, 309S, 304, 439, 204C2, 425M, 409L, 420J2, 436, 445, 304L, 405, 370, S32101, 904L, 444, 301LN, 305, 429, 304J1, 317L
|
|
Surface Finish
|
2B
|
|
Invoicing
|
by actual weight
|
|
Delivery Time
|
within 7 days
|
|
Product name
|
304 Stainless Angle Steel Bar
|
|
Shape
|
Equal Angle Bar
|
|
Technique
|
Hot Rolled Cold Rolled
|
|
MOQ
|
1 Ton
|
|
Material
|
200 Series/300 Series/400series
|
|
Package
|
Customer Request
|
|
Payment terms
|
30%T/T Advance + 70% Balance
|
|
Sample
|
Provide
|
|
Length
|
6-12m or customer's Requiremnts
|
|
Application
|
Building Construction Material
|
|
Product Name
|
stainless steel angle steel
|
|
Type
|
Stainless steel profile
|
|
Material (ASTM UNS)
|
201 202 304 304L 309s 310s 316 316L 316TI 317L 321 904L S32205
|
|
Standard
|
JIS/SUS/GB/DIN/ASTM/AISI/EN
|
|
Surface Finished
|
No.1 No.3 No.4 HL 2B BA 4K 8K 1D 2D
|
|
Technique
|
Cold Drawing or Hot Rolled or Casting
|
|
Packing
|
Standard Seaworthy Package or according to customer's requirements
|
|
Delivery Time
|
within 7-21 working days after reveiving the deposit or according to your order quantity
|
|
Package
|
Plywood Case/Pallet or Other Export Package Suitable for Long Distance Shipping
|
|
Chemical composition and mechanical properties of stainless stee coils
|
|||||||||
|
Grade
|
Chemical composition(%)
|
Mechanieal performece
|
|||||||
|
C
|
SI
|
MN
|
P
|
S
|
NI
|
CR
|
MO
|
Hardness
|
|
|
201
|
≤0.15
|
≤1.00
|
5.5/7.5
|
≤0.060
|
≤0.03
|
3.5/5.5
|
16/18
|
-
|
HB≤241HRB≤100HV≤204
|
|
304
|
≤0.08
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
8.0/11
|
18/20
|
-
|
HB≤187HRB≤90HV200
|
|
316
|
≤0.08
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
10/14
|
16/18
|
2/3
|
HB≤187HRB≤90HV200
|
|
316L
|
≤0.03
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
10/14
|
16/18
|
2/3
|
HB≤187HRB≤90HV200
|
|
410
|
≤0.15
|
≤1.00
|
≤1.25
|
≤0.060
|
≤0.03
|
≤0.60
|
11.5/13.5
|
-
|
HB≤183HRB≤88HV200
|
|
430
|
≤0.12
|
≤1.00
|
≤1.25
|
≤0.040
|
≤0.03
|
-
|
16/18
|
-
|
HB≤183HRB≤88HV200
|
FAQ
Q1: Can you send samples?
A:Of course, we can provide customers with free samples and express shipping service to all over of the world.
Q2: What product information do I need to provide?
A:Please kindly provide the grade, width, thickness, surface treatment requirement should you have and quantities you need to purchase.
Q3: It's my first time to import steel products, can you help me with it?
A:Sure,we have agent to arrange the shipment, we will do it together with you.
Q4: What ports of shipment are there?
A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can specify other ports according to your needs.
Q5: What about product prices information?
A:Prices various according to periodic price changes of raw materials.
Q6: What is your terms of payment ?
A:Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment or based on BL copy or LC at sight.
Q7: Do you provide custom made Products service?
A: Yes,if you have your own design , we can produce according to your specification and drawing.
Q8: What are the certifications for your products?
A:We have ISO 9001, MTC, third parties’ inspections are all available such SGS, BV ect.
Q9: How long does your delivery time take?
A:In general, our delivery time is within 7-15 days, and may be longer if the quantity is extremely large or special circumstances occur.
Q10: How many countries you already exported to?
A:We have exported to America, Canada, Brazil, Chile, Colombia, , Ukraine, Thailand, Myanmar, Vietnam, India, Kenya, Ghana,somalia and other African countries.Our export experience is rich, we familiar with different market demands, can help customers avoid a lot of trouble.
Q11: Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q12: Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed and customers can appoint third parties to inspect the products before loading too.
Q13: How to pack the products? A: Standard export sea-worthy packaging, the inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion and various climate changes during ocean transportation.
Q14: What is your working time? A:In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to your inquiry in the coming working day.
Contact Person: Jessie
Tel: +8613327919758
