Product Details:
|
| Standard: | AiSi | Type: | Equal |
|---|---|---|---|
| Model Number: | 310S, 410, 316Ti, 316L, 316, 321, 410S | Processing Service: | Bending, Welding, Decoiling, Punching, Cutting |
| Surface Finish: | 2B | Shape: | Equal Angle Bar |
| Grade: | 200 Series 300 Series 400 Series | Application: | Construction, Building Construction Material |
| Tolerance: | ±1% | Steel Grade: | 301L, S30815, 301, 304N, 310S, S32305, 410, 204C3, 316Ti, 316L, 441 |
| Product Name: | 304 Stainless Angle Steel Bar | Technique: | Hot Rolled Cold Rolled |
| Material: | 200 Series/300 Series/400series | Payment Terms: | 30%T/T Advance + 70% Balance |
| Length: | 6-12m Or Customer's Requiremnts | ||
| High Light: | 316 stainless steel angle,Stainless Steel Angle 40x3,304 stainless angle bar |
||
Factory Price AISI 201 304 316 Stainless Steel Angle Bar 40x3 45x4 50x5 SS Angle Bar With Stock
304/304L Stainless Angle, is a hot rolled stainless angle shape with inside radius corners that is ideal for all structural applications where greater strength and superior corrosion resistance is required. 304 Stainless Angle has a durable dull, grainy mill finish that is widely used for all types of fabrication projects that are exposed to the elements - chemical, acidic, fresh water, and salt water environments
|
Product Name
|
angle steel
|
|||
|
Material
|
Q235B,Q345B,Q420B/C,Q460C,SS400/SS540,S235JR/S235J0/S235J2,
S275JR/S275J0/S275J2,S355JR/S355J0/S355J2 |
|||
|
Specification
|
20*20--200*200mm
|
|||
|
Length
|
6m, 12m,Large quantity can be customized
|
|||
|
Technique
|
Hot Rolled
|
|||
|
Application
|
Widely used in various building structure and engineering structure, such as the beam, bridges, transmission tower, lifting transportation machinery, ship, industrial furnace, reaction tower and container frame etc.
|
|||
|
Payment terms
|
30% T/T deposit in advance, 70% T/T balance within 5 days after B/L copy, 100% Irrevocable L/C at sight, 100% Irrevocable L/C after receive B/L 30-120 days, O/A
|
|||
|
Packing
|
Tied up with steel strips and wrapped with water proof paper
|
|||
|
Delivery time
|
Usually 7-15 dyas, or upon negotiation
|
|||
|
item
|
value
|
|
Standard
|
AiSi
|
|
Grade
|
200 series 300 Series 400 series
|
|
Type
|
Equal
|
|
Application
|
Construction
|
|
Place of Origin
|
China
|
|
|
Jiangsu
|
|
Brand Name
|
Tisco
|
|
Model Number
|
310S, 410, 316Ti, 316L, 316, 321, 410S, 410L, 430, 309S, 304
|
|
Tolerance
|
±1%
|
|
Processing Service
|
Bending, Welding, Decoiling, Punching, Cutting
|
|
Steel Grade
|
301L, S30815, 301, 304N, 310S, S32305, 410, 204C3, 316Ti, 316L, 441, 316, L4, 420J1, 321, 410S, 410L, 436L, 443, LH, L1, S32304, 314, 347, 430, 309S, 304, 439, 204C2, 425M, 409L, 420J2, 436, 445, 304L, 405, 370, S32101, 904L, 444, 301LN, 305, 429, 304J1, 317L
|
|
Surface Finish
|
2B
|
|
Invoicing
|
by actual weight
|
|
Delivery Time
|
within 7 days
|
|
Product name
|
304 Stainless Angle Steel Bar
|
|
Shape
|
Equal Angle Bar
|
|
Technique
|
Hot Rolled Cold Rolled
|
|
MOQ
|
1 Ton
|
|
Material
|
200 Series/300 Series/400series
|
|
Package
|
Customer Request
|
|
Payment terms
|
30%T/T Advance + 70% Balance
|
|
Sample
|
Provide
|
|
Length
|
6-12m or customer's Requiremnts
|
|
Application
|
Building Construction Material
|
|
Product Name
|
stainless steel angle steel
|
|
Type
|
Stainless steel profile
|
|
Material (ASTM UNS)
|
201 202 304 304L 309s 310s 316 316L 316TI 317L 321 904L S32205
|
|
Standard
|
JIS/SUS/GB/DIN/ASTM/AISI/EN
|
|
Surface Finished
|
No.1 No.3 No.4 HL 2B BA 4K 8K 1D 2D
|
|
Technique
|
Cold Drawing or Hot Rolled or Casting
|
|
Packing
|
Standard Seaworthy Package or according to customer's requirements
|
|
Delivery Time
|
within 7-21 working days after reveiving the deposit or according to your order quantity
|
|
Package
|
Plywood Case/Pallet or Other Export Package Suitable for Long Distance Shipping
|
|
Chemical composition and mechanical properties of stainless stee coils
|
|||||||||
|
Grade
|
Chemical composition(%)
|
Mechanieal performece
|
|||||||
|
C
|
SI
|
MN
|
P
|
S
|
NI
|
CR
|
MO
|
Hardness
|
|
|
201
|
≤0.15
|
≤1.00
|
5.5/7.5
|
≤0.060
|
≤0.03
|
3.5/5.5
|
16/18
|
-
|
HB≤241HRB≤100HV≤204
|
|
304
|
≤0.08
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
8.0/11
|
18/20
|
-
|
HB≤187HRB≤90HV200
|
|
316
|
≤0.08
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
10/14
|
16/18
|
2/3
|
HB≤187HRB≤90HV200
|
|
316L
|
≤0.03
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
10/14
|
16/18
|
2/3
|
HB≤187HRB≤90HV200
|
|
410
|
≤0.15
|
≤1.00
|
≤1.25
|
≤0.060
|
≤0.03
|
≤0.60
|
11.5/13.5
|
-
|
HB≤183HRB≤88HV200
|
|
430
|
≤0.12
|
≤1.00
|
≤1.25
|
≤0.040
|
≤0.03
|
-
|
16/18
|
-
|
HB≤183HRB≤88HV200
|
FAQ
Q1: Can you send samples?
A:Of course, we can provide customers with free samples and express shipping service to all over of the world.
Q2: What product information do I need to provide?
A:Please kindly provide the grade, width, thickness, surface treatment requirement should you have and quantities you need to purchase.
Q3: It's my first time to import steel products, can you help me with it?
A:Sure,we have agent to arrange the shipment, we will do it together with you.
Q4: What ports of shipment are there?
A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can specify other ports according to your needs.
Q5: What about product prices information?
A:Prices various according to periodic price changes of raw materials.
Q6: What is your terms of payment ?
A:Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment or based on BL copy or LC at sight.
Q7: Do you provide custom made Products service?
A: Yes,if you have your own design , we can produce according to your specification and drawing.
Q8: What are the certifications for your products?
A:We have ISO 9001, MTC, third parties’ inspections are all available such SGS, BV ect.
Q9: How long does your delivery time take?
A:In general, our delivery time is within 7-15 days, and may be longer if the quantity is extremely large or special circumstances occur.
Q10: How many countries you already exported to?
A:We have exported to America, Canada, Brazil, Chile, Colombia, , Ukraine, Thailand, Myanmar, Vietnam, India, Kenya, Ghana,somalia and other African countries.Our export experience is rich, we familiar with different market demands, can help customers avoid a lot of trouble.
Q11: Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q12: Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed and customers can appoint third parties to inspect the products before loading too.
Q13: How to pack the products? A: Standard export sea-worthy packaging, the inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion and various climate changes during ocean transportation.
Q14: What is your working time? A:In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to your inquiry in the coming working day.
